The post CRBE 08022 A CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]> As a professional manufacturer of crossed roller bearing, we are committed to providing customers with high-quality products and perfect technical support.

CRBE 08022 A crossed roller bearing specification

  1. Model Code: CRBE series is high rigidity with mounting holes of crossed roller bearing.
  2. Outer Diameter: 165 (unit: mm).
  3. Bore Diameter:   80 (unit: mm).
  4. Width: 22 (unit: mm).
  5. Weight: 2.6 KG
  6. Mounting Holes:inner rings/PCD 97,mounting holes 10-M5 through.Outer rings/PCD 148,mounting holes 10-φ5.5 through φ9.5 counter bore depth 5.4 (unit: mm).
  7. Seal Symbol: WW signifies seals on both sides. NN signifies the open type without seals. Both types haveoil holes for lubrication.
  8. Axial internal clearance: C1 signifies positive clearance with less friction force, while C8 signifies negative clearance without back lash, which will result in an increase of friction force during unloading conditions.
  9. Accuracy class: Including P6,P5, P4,

Similar products of CRBE 08022 A crossed roller bearing

Bearing No. Bearing No. Bearing No. Bearing No. Bearing No. Bearing No.
CRBE08022A C8 P6 CRBE08022A C1 P6 CRBE08022A WW C8 P6 CRBE08022A WW C1 P6 CRBE08022A NN C8 P6 CRBE08022A NN C1 P6
CRBE08022A C8 P5 CRBE08022A C1 P5 CRBE08022A WW C8 P5 CRBE08022A WW C1 P5 CRBE08022A NN C8 P5 CRBE08022A NN C1 P5
CRBE08022A C8 P4 CRBE08022A C1 P4 CRBE08022A WW C8 P4 CRBE08022A WW C1 P4 CRBE08022A NN C8 P4 CRBE08022A NN C1 P4
CRBE08022A C8 P2 CRBE08022A C1 P2 CRBE08022A WW C8 P2 CRBE08022A WW C1 P2 CRBE08022A NN C8 P2 CRBE08022A NN C1 P2

How to ensure quality of  crossed roller bearing

–Advanced design

From the beginning of design stage, we make a modeling to design crossed roller bearing by advanced design software, then use method of finite element analysis to verify the results.

–Advanced equipment

Base on advanced equipment to ensure product quality, we possess advance processing equipment for key production process, for example, CNC machining center, CNC heat treatment equipment …etc.

–Reliable raw materials

The most important part of ensuring the product quality is raw materials manufacturing, therefore we choose the reliable raw materials to use for element of crossed roller bearing, such as bearing ring and roller etc, we also could provide customize crossed roller bearing with special material.

–Perfect management system

We established perfect management system so to ensure product quality, we passed to certificate ISO9001 quality management system as well as obtain ISO9001 certification, and carry out quality manufacture system strictly for whole process of production from beginning to the end.

–Perfect testing method

We organized a professional and strong testing and inspecting team with advanced test equipment by perfect testing method to guarantee product quality and set up special testing machine and test bed for crossed roller bearing.

CRBE 08022 A HIWIN CROSSED ROLLER BEARING;HIWIN CROSSED ROLLER BEARING;HIWIN CROSSED ROLLER BEARING;HIWIN CROSSED ROLLER BEARING;HIWIN CROSSED ROLLER BEARING;HIWIN CROSSED ROLLER BEARING

Download : drawing of crossed roller bearing CRBE 08022 A

If you need formal drawing , please contact with us

Contact information

Luoyang JCB Bearing Technology Company Limited

Company Address: No. 285, Fenghua Road, High-tech Development Zone, Luoyang Area, (Henan) Free Trade Zone of China.

Postal code : 471000

Phone : 0086-379-6861-1678 Fax : 0086-379-6861-1679

WhatsApp：+8618603795853

E-mail:   sales@jcb-bearing.com  

Reserved E-mail:  jcb-bearing@hotmail.com 

www.cross-roller-bearing.com

The post CRBE 08022 A CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]> NRXT 13025DD CROSSED ROLLER BEARING https://www.cross-roller-bearing.com/product/nrxt-13025dd-of-nsk-cross-roller-bearing/ Mon, 23 Apr 2018 06:43:01 +0000 http://www.cross-roller-bearing.com/?post_type=product&p=646 Bearing No. Boundary dim.（mm） Basic loading rates(N) Oil Hole(mm) Abutment and Fillet Dim.(mm) Weight d D B rmin C Co doh ramax kg NRXT 13025DD 130 190 25 1.1 72500 118000 2.5 1 2.63

The post NRXT 13025DD CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]> As a professional manufacturer of crossed roller bearing, we are committed to providing customers with high-quality products and perfect technical support.

NRXT 13025DD crossed roller bearing specification

  1. Model Code: NRXT…DD series is split outer ring type of crossed roller bearing with separator.
  2. Outer Diameter: 190 (unit: mm).
  3. Bore Diameter:   130 (unit: mm).
  4. Width: 25 (unit: mm).
  5. Weight: 2.63 KG
  6. Mounting Holes: without mounting holes.
  7. Seal Symbol: DD signifies seals on both sides.
  8. Axial internal clearance: C1 signifies positive clearance, while C8 signifies negative clearance.
  9. Accuracy class: Including P6,P5,P4,P2.

Similar products of NRXT 13025DD crossed roller bearing

Bearing No. Bearing No. Bearing No. Bearing No.
NRXT13025DD C1 P6 NRXT13025DD C1 P5 NRXT13025DD C1 P4 NRXT13025DD C1 P2
NRXT13025DD C8 P6 NRXT13025DD C8 P5 NRXT13025DD C8 P4 NRXT13025DD C8 P2

How to ensure quality of  crossed roller bearing

–Advanced design

From the beginning of design stage, we make a modeling to design crossed roller bearing by advanced design software, then use method of finite element analysis to verify the results.

–Advanced equipment

Base on advanced equipment to ensure product quality, we possess advance processing equipment for key production process, for example, CNC machining center, CNC heat treatment equipment …etc.

–Reliable raw materials

The most important part of ensuring the product quality is raw materials manufacturing, therefore we choose the reliable raw materials to use for element of crossed roller bearing, such as bearing ring and roller etc, we also could provide customize crossed roller bearing with special material.

–Perfect management system

We established perfect management system so to ensure product quality, we passed to certificate ISO9001 quality management system as well as obtain ISO9001 certification, and carry out quality manufacture system strictly for whole process of production from beginning to the end.

–Perfect testing method

We organized a professional and strong testing and inspecting team with advanced test equipment by perfect testing method to guarantee product quality and set up special testing machine and test bed for crossed roller bearing.

NRXT 13025DD NSK CROSSED ROLLER BEARING

Download : drawing of crossed roller bearing NRXT 13025DD

If you need formal drawing , please contact with us

Contact information

Luoyang JCB Bearing Technology Company Limited

Company Address: No. 285, Fenghua Road, High-tech Development Zone, Luoyang Area, (Henan) Free Trade Zone of China.

Postal code : 471000

Phone : 0086-379-6861-1678 Fax : 0086-379-6861-1679

WhatsApp：+8618603795853

E-mail:   sales@jcb-bearing.com  

Reserved E-mail:  jcb-bearing@hotmail.com 

www.cross-roller-bearing.com

The post NRXT 13025DD CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]> CRBHV 3510 A CROSSED ROLLER BEARING https://www.cross-roller-bearing.com/product/crbhv-3510-a-of-iko-cross-roller-bearing/ Mon, 23 Apr 2018 02:47:25 +0000 http://www.cross-roller-bearing.com/?post_type=product&p=443 Bearing No. Boundary dim.（mm） Basic loading rates(N) Mounting dimensions(mm) Weight d D B rmin C Co da Da kg CRBHV 3510A 35 60 10 0.3 7900 9130 41.5 53.5 0.13

The post CRBHV 3510 A CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]> As a professional manufacturer of crossed roller bearing, we are committed to providing customers with high-quality products and perfect technical support.

CRBHV 3510 A crossed roller bearing specification

  1. Model Code: CRBHV…A series is high rigidity type of crossed roller bearing V with separator.
  2. Outer Diameter: 60 (unit: mm).
  3. Bore Diameter:  35 (unit: mm).
  4. Width: 10 (unit: mm).
  5. Weight: 0.13 KG
  6. Mounting Holes: without mounting holes.
  7. Seal Symbol: No symbol signifies the open type without seals.( UU signifies seals on both sides. U signifies seal on one side.UD signifies seal on one side  in the opposite direction to counter bored mounting holes on outer ring.)
  8. Axial internal clearance: T1,C1,C2
  9. Accuracy class: Including P6,P5, P4, P2

Radial internal clearance

Nominal bore diameter of bearing(mm) T1(μm) C1(μm) C2(μm)
over incl. Min. Max. Min. Max. Min. Max.
– 20 -10 0 0 10 10 20
20 25 -10 0 0 10 10 20
25 35 -10 0 0 10 10 25
35 45 -10 0 0 10 10 25
45 65 -10 0 0 15 15 30
65 80 -10 0 0 15 15 35
80 95 -15 0 0 15 15 35
95 110 -15 0 0 20 20 45
110 125 -15 0 0 20 20 50

Similar products of CRBHV 3510 A crossed roller bearing

Bearing No. Bearing No. Bearing No. Bearing No. Bearing No.
CRBHV3510 A T1 CRBHV3510 A T1 P6 CRBHV3510 A T1 P5 CRBHV3510 A T1 P4 CRBHV3510 A T1 P2
CRBHV3510 A C1 CRBHV3510 A C1 P6 CRBHV3510 A C1 P5 CRBHV3510 A C1 P4 CRBHV3510 A C1 P2
CRBHV3510 A C2 CRBHV3510 A C2 P6 CRBHV3510 A C2 P5 CRBHV3510 A C2 P4 CRBHV3510 A C2 P2
CRBHV3510 A UU T1 CRBHV3510 A UU T1 P6 CRBHV3510 A UU T1 P5 CRBHV3510 A UU T1 P4 CRBHV3510 A UU T1 P2
CRBHV3510 A UU C1 CRBHV3510 A UU C1 P6 CRBHV3510 A UU C1 P5 CRBHV3510 A UU C1 P4 CRBHV3510 A UU C1 P2
CRBHV3510 A UU C2 CRBHV3510 A UU C2 P6 CRBHV3510 A UU C2 P5 CRBHV3510 A UU C2 P4 CRBHV3510 A UU C2 P2

How to ensure quality of  crossed roller bearing

–Advanced design

From the beginning of design stage, we make a modeling to design crossed roller bearing by advanced design software, then use method of finite element analysis to verify the results.

–Advanced equipment

Base on advanced equipment to ensure product quality, we possess advance processing equipment for key production process, for example, CNC machining center, CNC heat treatment equipment …etc.

–Reliable raw materials

The most important part of ensuring the product quality is raw materials manufacturing, therefore we choose the reliable raw materials to use for element of crossed roller bearing, such as bearing ring and roller etc, we also could provide customize crossed roller bearing with special material.

–Perfect management system

We established perfect management system so to ensure product quality, we passed to certificate ISO9001 quality management system as well as obtain ISO9001 certification, and carry out quality manufacture system strictly for whole process of production from beginning to the end.

–Perfect testing method

We organized a professional and strong testing and inspecting team with advanced test equipment by perfect testing method to guarantee product quality and set up special testing machine and test bed for crossed roller bearing.

CRBHV 3510 A IKO CROSSED ROLLER BEARING

Download : drawing of crossed roller bearing CRBHV 3510 A

If you need formal drawing , please contact with us

Contact information

Luoyang JCB Bearing Technology Company Limited

Company Address: No. 285, Fenghua Road, High-tech Development Zone, Luoyang Area, (Henan) Free Trade Zone of China.

Postal code : 471000

Phone : 0086-379-6861-1678 Fax : 0086-379-6861-1679

WhatsApp：+8618603795853

E-mail:   sales@jcb-bearing.com  

Reserved E-mail:  jcb-bearing@hotmail.com 

www.cross-roller-bearing.com

The post CRBHV 3510 A CROSSED ROLLER BEARING appeared first on CROSSED ROLLER BEARING.

]]>
